建立你自己的 CA 服务：OpenSSL 命令行 CA 操作快速指南

这些是关于使用 OpenSSL 生成证书授权（CA）、中间证书授权和末端证书的速记随笔，内容包括 OCSP、CRL 和 CA 颁发者信息，以及指定颁发和有效期限等。

我们将建立我们自己的根 CA，我们将使用根 CA 来生成一个中间 CA 的例子，我们将使用中间 CA 来签署末端用户证书。

根 CA

创建根 CA 授权目录并切换到该目录：

mkdir ~/SSLCA/root/
cd ~/SSLCA/root/

为我们的根 CA 生成一个8192位长的 SHA-256 RSA 密钥：

openssl genrsa -aes256 -out rootca.key 8192

样例输出：

Generating RSA private key, 8192 bit long modulus
.........++
....................................................................................................................++
e is 65537 (0x10001)

如果你想要用密码保护该密钥，请添加 -aes256 选项。

创建自签名根 CA 证书 ca.crt；你需要为你的根 CA 提供一个身份：

openssl req -sha256 -new -x509 -days 1826 -key rootca.key -out rootca.crt

样例输出：

You are about to be asked to enter information that will be incorporated
into your certificate request.
What you are about to enter is what is called a Distinguished Name or a DN.
There are quite a few fields but you can leave some blank
For some fields there will be a default value,
If you enter '.', the field will be left blank.
--
Country Name (2 letter code) [AU]:NL
State or Province Name (full name) [Some-State]:Zuid Holland
Locality Name (eg, city) []:Rotterdam
Organization Name (eg, company) [Internet Widgits Pty Ltd]:Sparkling Network
Organizational Unit Name (eg, section) []:Sparkling CA
Common Name (e.g. server FQDN or YOUR name) []:Sparkling Intermediate CA
Email Address []:

Please enter the following 'extra' attributes
to be sent with your certificate request
A challenge password []:
An optional company name []:

确保中间 CA 的主体（CN）和根 CA 不同。

用根 CA 签署中间 CA 的 CSR：

openssl ca -batch -config ca.conf -notext -in intermediate1.csr -out intermediate1.crt

样例输出：

Using configuration from ca.conf
Check that the request matches the signature
Signature ok
The Subject's Distinguished Name is as follows
countryName           :PRINTABLE:'NL'
stateOrProvinceName   :ASN.1 12:'Zuid Holland'
localityName          :ASN.1 12:'Rotterdam'
organizationName      :ASN.1 12:'Sparkling Network'
organizationalUnitName:ASN.1 12:'Sparkling CA'
commonName            :ASN.1 12:'Sparkling Intermediate CA'
Certificate is to be certified until Mar 30 15:07:43 2017 GMT (730 days)

Write out database with 1 new entries
Data Base Updated

生成 CRL（同时采用 PEM 和 DER 格式）：

openssl ca -config ca.conf -gencrl -keyfile rootca.key -cert rootca.crt -out rootca.crl.pem

openssl crl -inform PEM -in rootca.crl.pem -outform DER -out rootca.crl

每次使用该 CA 签署证书后，请生成 CRL。

如果你需要撤销该中间证书：

openssl ca -config ca.conf -revoke intermediate1.crt -keyfile rootca.key -cert rootca.crt

配置中间 CA

为该中间 CA 创建一个新文件夹，然后进入该文件夹：

mkdir ~/SSLCA/intermediate1/
cd ~/SSLCA/intermediate1/

从根 CA 拷贝中间证书和密钥：

cp ~/SSLCA/root/intermediate1.key ./
cp ~/SSLCA/root/intermediate1.crt ./

创建索引文件：

touch certindex
echo 1000 > certserial
echo 1000 > crlnumber

创建一个新的 ca.conf 文件：

# vim ca.conf
[ ca ]
default_ca = myca

[ crl_ext ]
issuerAltName=issuer:copy
authorityKeyIdentifier=keyid:always

 [ myca ]
 dir = ./
 new_certs_dir = $dir
 unique_subject = no
 certificate = $dir/intermediate1.crt
 database = $dir/certindex
 private_key = $dir/intermediate1.key
 serial = $dir/certserial
 default_days = 365
 default_md = sha1
 policy = myca_policy
 x509_extensions = myca_extensions
 crlnumber = $dir/crlnumber
 default_crl_days = 365

 [ myca_policy ]
 commonName = supplied
 stateOrProvinceName = supplied
 countryName = optional
 emailAddress = optional
 organizationName = supplied
 organizationalUnitName = optional

 [ myca_extensions ]
 basicConstraints = critical,CA:FALSE
 keyUsage = critical,any
 subjectKeyIdentifier = hash
 authorityKeyIdentifier = keyid:always,issuer
 keyUsage = digitalSignature,keyEncipherment
 extendedKeyUsage = serverAuth
 crlDistributionPoints = @crl_section
 subjectAltName  = @alt_names
 authorityInfoAccess = @ocsp_section



[alt_names]

DNS.0 = example.com DNS.1 = example.org

[crl_section]

URI.0 = http://pki.sparklingca.com/SparklingIntermidiate1.crl URI.1 = http://pki.backup.com/SparklingIntermidiate1.crl

[ocsp_section]

caIssuers;URI.0 = http://pki.sparklingca.com/SparklingIntermediate1.crt caIssuers;URI.1 = http://pki.backup.com/SparklingIntermediate1.crt OCSP;URI.0 = http://pki.sparklingca.com/ocsp/ OCSP;URI.1 = http://pki.backup.com/ocsp/

修改 [alt_names] 部分，添加你需要的主体备选名。如果你不需要主体备选名，请移除该部分包括subjectAltName = @alt_names的行。

如果你需要设置一个指定的生效/到期日期，请添加以下内容到 [myca]：

# format: YYYYMMDDHHMMSS
default_enddate = 20191222035911
default_startdate = 20181222035911

生成一个空白 CRL（同时以 PEM 和 DER 格式）：

openssl ca -config ca.conf -gencrl -keyfile rootca.key -cert rootca.crt -out rootca.crl.pem

openssl crl -inform PEM -in rootca.crl.pem -outform DER -out rootca.crl

生成末端用户证书

我们使用这个新的中间 CA 来生成一个末端用户证书，请重复以下操作来使用该 CA 为每个用户签署。

mkdir enduser-certs

生成末端用户的私钥：

openssl genrsa -out enduser-certs/enduser-example.com.key 4096

生成末端用户的 CSR：

openssl req -new -sha256 -key enduser-certs/enduser-example.com.key -out enduser-certs/enduser-example.com.csr

样例输出：

You are about to be asked to enter information that will be incorporated
into your certificate request.
What you are about to enter is what is called a Distinguished Name or a DN.
There are quite a few fields but you can leave some blank
For some fields there will be a default value,
If you enter '.', the field will be left blank.
